Nicet Highway Construction Inspector Level Iii Practice Exam 1 With 100% Correct Answers Already Graded A+

Which type of steel beam connection consist of beams that are linked to supporting elements (such as steel girders of columns) with a web connection angle? a) bolted framed connections b) bolted seated connections c) welded framed connections d) welded seat connections {Ans: a) bolted framed connections}The contractor is installing a culvert with a 12-inch reinforced concrete pipe ( outside diameter of 16.50 inches) from Sta 10+00, 40 feet Left to STA 10+00, 65 feet Right on 4-inch bedding material. The 12-inch RCP outlet is to be installed at Sta 10+00, 40 feet Left at an invert elevation of 652.50. If the conduit is installed at a 1.40% slope, what is the elevation of the foundation grade at Sta 10+00, 45 feet Right? a) 652.04 b) 653.17 c) 653.36 d) 653.50 {Ans: ?}For which of the following problems might slab stabilization be the most appropriate repair method? a) corner breaks in PCC pavement b) potholes in HMA pavement c) shattered PCC slab d) voids in PCC pavement caused by pumping {Ans: d) voids in PCC pavement caused by pumping}Which equipment is suitable for compacting select granular backfill within 36 inches of a mechanically stabilized earth (MSE) wall
